Features:

·         Support USB 2.0, all brands and various capacities of USB flash drive.

·         Large file size support, upto 4GB.

·         Long file names support, upto 50 characters

·         Extension of file name supports: *.?NC, *.TXT,*.NC, *.TAP

·         User Communications Settings

·         Select the files you want to transfer in a list displayed on the LCD screen easily and simply.

·         Support Fanuc tape parallel and serial rs232 communications

·         Support view CNC program file before transfer.

·         Transfer/Receive CNC program to/from CNC machine.

·         Drip Feed - if supported by CNC

·         Backup parameters from CNC machine to USB flash drive.

·         Repeat last file sent to CNC "t" times

·         ASCII, ISO and EIA codesets are fully supported.

·         AutoCut program - Usefully when you are running a large job and your tool breaks then you would have to start from where you left off.

·         Integrated timer - Allow you to set the time to stop CNC machine periodically for change the tool when the tool is over lifespan

Specifications:

·         Dimension(W/H/D):  Approx 150mm/30mm/100mm

·         Weight:  300g (10.5 oz)

·         Display:  Text LCD 16x2 - display list of program file, status, parameter setting, error,...

·         Diagnostics LED:  Power, Ready, Send, Request, Error

·         User Button:  Up, Select, Down, Reset

·         Input:  2 USB ports, 1 DC power port.

·         Output:   Fanuc Tape parallel, serial rs232

·         Power supply: 12V DC – 1A power supply adapter, or draw power from the rs232 port or parallel port.
